We are offering for sale a 2017 DMG CMX 600 V CNC milling center, which is the ideal choice for anyone looking for a reliable and high-performance machine for demanding machining applications. The machine has very low operating hours, approximately 2,038 hours.

Key parameters:

Max. travel along the X-axis: 600 mm
Max. travel in the Y-axis: 560 mm
Max. travel along the Z-axis: 510 mm
Max. workpiece height: 630 mm
Max. workpiece weight: 600 kg
Max. workpiece length: 900 mm
Max. workpiece width: 560 mm
Controls and Software: SIEMENS

Key Benefits:

High precision – The machine is equipped with direct measurement and achieves positioning accuracy of up to 6 micrometers (without linear measurement according to ISO 230-2).
High-quality construction – The C-frame design ensures maximum rigidity for stability during demanding machining operations.
Exceptional Ergonomics – An improved design featuring a table that moves along the X-axis and a rigid Y-axis for easy handling of heavy workpieces.
Optimization for Efficiency – The machine is equipped with the IoTconnector system, which enables real-time connection and monitoring of machine parameters.

Technical Specifications:

C-frame for maximum rigidity, ensuring stability even during demanding machining operations
An improved C-frame design with an X-axis-movable table for greater precision
The rigidity of the Y-axis across its entire travel range ensures optimal results
Design optimized using the finite element method for outstanding strength and precision
Thermal compensation for stability and high-quality production
Positioning accuracy of 6 micrometers without linear measurement (according to ISO 230-2)
High-quality ball screws with an IT 1 tolerance
The large worktable, measuring 900 × 560 mm, allows for the machining of heavy workpieces weighing up to 600 kg
Ergonomic design for easy handling and loading of heavy parts

Intuitive controls:

The machine is equipped with a 19″ DMG MORI SLIMline multi-touch control panel, which offers intuitive and simple operation for efficient and precise machining. Combined with SIEMENS software, operating the machine is easy and straightforward.

Why the DMG CMX 600 V?

The DMG CMX 600 V CNC milling center is ideal for a wide range of applications thanks to its robust design, high precision, and advanced features. Whether for the precise machining of complex parts or demanding manufacturing processes, this machine delivers top-notch performance.

If you’d like more information or are interested in purchasing this machine, please don’t hesitate to contact us. You can find more information about the product and our contact details here.

For more information about this machine, visit the manufacturer’s official website: DMG MORI CMX 600 V.

Price: Upon request

If you have any questions or would like to schedule a tour, please contact us at info@sedlacek-t.cz or by phone at +420 725 586 141.
